Advanced School Microscope Manufacturer,Supplier and Exporter in India
Product Code : PHM-11355
Quick answer. Advanced School Microscope — Focussing : Separate knobs are provided for coarse and fine focussing adjustments. Supplied by Pharmacy Lab Equipment, Ambala.
Description
Coarse adjustment can be made through Rack-Pinion and fine movement by screw-lever mechanism having a graduated knob on the right side. Condenser : Bright field, Abbe N.A. 1.25 with iris diaphragm and swing out filter holder can be moved through rack-pinion. The condenser Unit incorporates high efficiency optical system for optimum utilization of light from low to high magnification.
Technical specifications
| Specification | Value |
|---|---|
| Safety Device | Adjustable down movement stopper for preventing accidental damage to slides. |
| Stand | Stable and Robust, assembled from Aluminium DIE-CAST parts. |
| Body | Monocular Tube inclinable upto 90°, Mechanical Tube length 160mm. |
| Stage | Graduated mechanical stage size 120x120mm with convenient adjustment for slide manipulation upto 40x75mm. |
| Nosepiece | Quadruple revolving nosepiece with positive centering & click stops. |
| Illumination | Plano-Concave Mirror diameter 50mm mounted on gimbal mount. |
| Objectives | Achromatic 10x, 40x SL and 100x SL Oil Immersion. |
| Packing | In full mould Styrofoam/Thermocol Container. |
| Optional | Coaxial Mechanical Stage, Wooden Storing Cabinet with Lock and Key, Draw Tube, Spare Objectives, Sub-Stage Lamp for 220/110V (with extra charges). |
| Eyepieces | Huygenian 5x, 6x, 10x, 15x (any two) or Wide Field 10x. |
| Accessories | Vinyl Cover, Duster, Cleaning Brush, Filter. |
Confirm the full specification, the standard accessories supplied and the warranty terms against your requirement before ordering.
