Comfy I.C.U. Bed, Electric, 7 Function (With X-Ray Permeable Backrest) Column Model Manufacturer,Supplier and Exporter in India
ColumnModel.jpg)
Product Code : PHIB-11829
Quick answer. Comfy I.C.U. Bed, Electric, 7 Function (With X-Ray Permeable Backrest) Column Model — Comfy ICU Bed (7 function) with electrically operated back rest tilting 0-70º, knee rest tilting 0-30°, trendelenburg tilting 0-12°,Reverse trendelenburg tilting 0-12°, mattress base ( lateral ) tilting to the left up to 15°, tilting to the right up to 15°. Supplied by Pharmacy Lab Equipment, Ambala.
Description
Angle Gauge on Side rails display's the angle of back rest, Lateral tilt and Trendelenburg / Reverse Trendelenburg. Embedded controls on both sides of guard rails, Linen shelf : At the bottom of foot end. Manual/Electric CPR : The Electric CPR operates with one key control. Manual CPR is equipped with damping device, which can be used single handedly and allows the back rest fall slowly to ensure the safety of the patient, in case of power failure.
Product details
- With X-ray permeable backrest, Central nurse control system
Basic Features
Technical specifications
| Specification | Value |
|---|---|
| Size | L 2240 mm ×W 1055 mm × H 520--920 mm (Adjustable Height). °. Bed extension -200 mm(+- 10 mm) |
| H/F boards locks | The board locks prevent accidental removal of the bed boards when steering or handing the bed |
| Split Guard Rails | Guard rail PP- 4 pcs provides protection to patient and additional side rails- 2 pcs near foot board offers more safety and support to patient while standing. |
| Integrated Scale control panel | It is located at foot end and is protected against impacts. |
| X-ray cassette holder | Sliding construction allows the cassette to be inserted beneath the mattress platform from the side of the bed. |
| Removable mattress platform | Plastic board mattress platform can be easily removed for sterilization. |
| Model | PHIB-11829 |
| Function | Seven |
| Outer dimensions(Side rails up) | L2240*W1055mm (±10mm) |
| Mattress platform | L1965*W920mm (±10mm) |
| Bed Height | H520-920mm (±10mm) |
| Bed extension | 200mm (±10mm) |
| Maximum backrest angle | ≥70° |
| Maximum thigh rest | ≥30° |
| TR/ATR | ≥12° |
| Left and right tilt | ≥15° |
| Height of side rails (above mattress platform) | 440mm (±10mm) |
| Safe working load | 200kgs |
| Weighing system | Yes |
Confirm the full specification, the standard accessories supplied and the warranty terms against your requirement before ordering.
